Acura Integra IV (2022-2024) front passenger's door switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door switch, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door switch (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR LATCH
DRIVER'S DOOR SWITCH
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE SENSOR
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR SWITCH
FUSE 11
GRN WIRE
GRY WIRE
HOT W/
JUNCTION BOX B
JUNCTION BOX G
LEFT REAR DOOR LATCH
LEFT REAR DOOR SWITCH
LT GRN WIRE
OPTION CONNECTOR (DRIVER'S DOOR)
OPTION CONNECTOR (FRONT PASSENGER'S DOOR)
PCM
PNK WIRE
PPL
PPL/TAN WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR SWITCH
TAN WIRE
THERMAL JOINT 4
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Chime circuit (1 of 2) -> FRONT PASSENGER'S DOOR SWITCH
