Acura Integra IV (2022-2024) driver's seat belt outer lap tensioner Wiring diagram
This page shows the only wiring diagram for the component.driver's seat belt outer lap tensioner, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat belt outer lap tensioner (1 of 1)
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BELT OUTER LAP TENSIONER
DRIVER'S SEAT BELT TENSIONER
DRIVER'S SIDE AIR BAG INFLATOR
F-CAN L F-CAN H
F-CAN TRANSCEIVER
FRONT PASSENGER'S SEAT BELT OUTER LAP TENSIONER
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
FUSE 6
GAUGE CONTROL MODULE
GRN WIRE
JUNCTION BOX D
LEFT REAR SIDE AIR BAG INFLATOR
LEFT SIDE CURTAIN AIR BAG INFLATOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT REAR SIDE AIR BAG INFLATOR
RIGHT SIDE CURTAIN AIR BAG INFLATOR
SEAT BELT REMINDER IND
SELECTABLE ENERGY ABSORPTION DEVICE
SRS IND
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 4) -> DRIVER'S SEAT BELT OUTER LAP TENSIONER
