Acura Integra IV (2022-2024) driver's power seat slide motor Wiring diagrams
This page contains all the electrical diagrams for the component. driver's power seat slide motor, in which he is found in the car Acura Integra IV (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's power seat slide motor (1 of 2)
BACKWARD
BLK WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT HEIGHT MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT SLIDE MOTOR
DRIVER'S POWER SEAT TILT MOTOR
FORWARD/
FRONT UP-DOWN SWITCH
FUSE 40
FUSE 41
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> DRIVER'S POWER SEAT SLIDE MOTOR
Wiring diagram driver's power seat slide motor (2 of 2)
Go to component -> Memory systems circuit (2 of 2) -> DRIVER'S POWER SEAT SLIDE MOTOR
