Acura Integra IV (2022-2024) driver's power seat height motor Wiring diagrams
This page contains all the electrical diagrams for the component. driver's power seat height motor, in which he is found in the car Acura Integra IV (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's power seat height motor (1 of 2)
BACKWARD
BLK WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S POWER SEAT HEIGHT MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT SLIDE MOTOR
DRIVER'S POWER SEAT TILT MOTOR
FORWARD/
FRONT UP-DOWN SWITCH
FUSE 40
FUSE 41
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> DRIVER'S POWER SEAT HEIGHT MOTOR
Wiring diagram driver's power seat height motor (2 of 2)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S POWER SEAT HEIGHT MOTOR
DRIVER'S POWER SEAT RECLINE MOTOR
DRIVER'S POWER SEAT TILT MOTOR
FUSE 11
FUSE 19
FUSE 40
FUSE 41
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
JUNCTION BOX B
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ 2 WAY TRANSCEIVER
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (1 of 2) -> DRIVER'S POWER SEAT HEIGHT MOTOR
