Acura Integra IV (2022-2024) down right Wiring diagram
This page shows the only wiring diagram for the component.down right, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down right (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BSI ALERT IND
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DEFOGGER SYSTEM
DOOR MULTIPLEX CONTROL UNIT
DOWN RIGHT
DOWN/ LEFT
EXTERIOR LIGHTS, DEFOGGER SYSTEMS
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 1
FUSE 2
FUSE 43
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
JUNCTION BOX A
JUNCTION BOX F
LEFT
LEFT POWER MIRROR
LT BLU WIRE
LT GRN WIRE
MIRROR ACTUATOR
MIRROR DEFOGGER
MIRROR POSITION SENSOR
NAVIGATION SYSTEM
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RELAY ENERGIZED
RIGHT
RIGHT LEFT
RIGHT POWER MIRROR
SIDE TURN SIGNAL LIGHT (LEDS)
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UP LEFT
UP/ RIGHT
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> DOWN RIGHT
