Acura Integra IV (2022-2024) dc-dc converter acc relay Wiring diagrams

This page contains all the electrical diagrams for the component. dc-dc converter acc relay, in which he is found in the car Acura Integra IV (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram dc-dc converter acc relay (1 of 4)

Wiring diagram dc-dc converter acc relay for Acura Integra IV (2022-2024) (1 of 4)

Get access

A/C CONDENSER FAN MOTOR AUTOMATIC DIMMING INSIDE MIRROR AUTOMATIC LIGHTING/ RAIN SENSOR BLK WIRE BODY CONTROL MODULE BRAKE FLUID LEVEL SWITCH CLUTCH PEDAL POSITION SWITCH A DATA LINK CONNECTOR (DLC) DC-DC CONVERTER DC-DC CONVERTER ACC RELAY DRIVER'S VANITY MIRROR LIGHT ELECTRIC VACUUM PUMP CONTROL UNIT FRONT ACCESSORY POWER SOCKET RELAY FRONT INDIVIDUAL MAP LIGHT FRONT SEAT HEATER RELAY HEAD-UP DISPLAY HEATED STEERING WHEEL RELAY HOOD LATCH SWITCH HORN (HIGH)/ SECURITY HORN HORN (LOW)/ SECURITY HORN M/T MOONROOF MOTOR/ CONTROL UNIT MOONROOF SWITCH MULTI-PURPOSE CAMERA UNIT PASSENGER'S VANITY MIRROR LIGHT POWER DOOR LOCK RELAY (DR UNLOCK) POWER DOOR LOCK RELAY (LOCK) POWER DOOR LOCK RELAY (UNLOCK) POWER TRANSISTOR POWER WINDOW MASTER SWITCH RELAY CONTROL MODULE RIGHT FRONT FOG LIGHT RIGHT HEADLIGHT TAILGATE RELEASE ACTUATOR RELAY UNDER-HOOD FUSE/RELAY BOX VSA OFF SWITCH WASHER FLUID LEVEL SWITCH WINDSHIELD WASHER MOTOR WINDSHIELD WIPER CONTROL UNIT/ MOTOR

Go to component -> Ground distribution circuit (4 of 4) -> DC-DC CONVERTER ACC RELAY

Wiring diagram dc-dc converter acc relay (2 of 4)

Wiring diagram dc-dc converter acc relay for Acura Integra IV (2022-2024) (2 of 4)

Get access

AUDIO UNIT B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DC-DC CONVERTER ACC RELAY FUSE 36 FUSE CC FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GNSS ANTENNA GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER LIN TRANSCEIVER LT BLU WIRE LT GRN WIRE NCA WIRE PCM PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER ROOF ANTENNA UNDER- HOOD FUSE/ RELAY BOX WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 3) -> DC-DC CONVERTER ACC RELAY

Wiring diagram dc-dc converter acc relay (3 of 4)

Wiring diagram dc-dc converter acc relay for Acura Integra IV (2022-2024) (3 of 4)

Get access

ANC/ ACTIVE SOUND CONTROL UNIT AUDIO ACC DIODE AUDIO UNIT BLK WIRE BLU WIRE BODY CONTROL MODULE BRAKE PEDAL POSITION SWITCH BRN WIRE CAN GATEWAY COMPUTER DATA LINES SYSTEM CVT DC-DC CONVERTER DC-DC CONVERTER ACC RELAY DRIVER'S POWER SEAT CONTROL UNIT FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6) FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6) FRONT USB CHARGER UNIT FUSE 36 FUSE C FUSE D FUSE E FUSE H FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE JUNCTION BOX B JUNCTION BOX D JUNCTION BOX D (DIAGRAM 2 OF 6) JUNCTION BOX E LEFT SIDE BSI RADAR UNIT LT BLU WIRE LT GRN WIRE M/T MULTI-PURPOSE CAMERA UNIT PARK PIN SWITCH/ SHIFT LOCK SOLENOID PARKING, BACKUP SENSOR CONTROL UNIT PCM PNK WIRE PPL REAR USB CHARGER UNIT RED WIRE RIGHT SIDE BSI RADAR UNIT SHIFT POSITION INDICATOR TAN WIRE TELEMATICS CONTROL UNIT TO FUSE A (DIAGRAM 4 OF 6) TURBOCHARGER BYPASS CONTROL SOLENOID VALVE UNDER-HOOD FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6) UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6) W/O AMPLIFIER WHT WIRE WIRELESS CHARGER YEL WIRE

Go to component -> Power distribution circuit (6 of 6) -> DC-DC CONVERTER ACC RELAY
