Acura Integra IV (2022-2024) cvt drive pulley speed sensor Wiring diagram
This page shows the only wiring diagram for the component.cvt drive pulley speed sensor, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cvt drive pulley speed sensor (1 of 1)
ACC COMBINATION SWITCH
AUDIO REMOTE- HFL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CVT DRIVE PULLEY SPEED SENSOR
CVT DRIVEN PULLEY PRESSURE SENSOR
CVT SPEED SENSOR
DIODE B
FUSE 45
FUSE D
FUSE F
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
HOT W/ DC-DC CONVERTER
JUNCTION BOX B
JUNCTION BOX D
LT BLU WIRE
LT GRN WIRE
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PNK WIRE
PPL
RED WIRE
TAN WIRE
TORQUE CONVERTER TURBINE SPEED SENSOR
TRANSMISSION FLUID TEMPERATURE SENSOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Transmission circuit (2 of 3) -> CVT DRIVE PULLEY SPEED SENSOR
