Acura Integra IV (2022-2024) brake booster pressure sensor 1 Wiring diagram
This page shows the only wiring diagram for the component.brake booster pressure sensor 1, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake booster pressure sensor 1 (1 of 1)
ABS IND.
AUTOMATIC BRAKE
BLK WIRE
BLU WIRE
BRAKE BOOSTER PRESSURE SENSOR 1
BRAKE BOOSTER PRESSURE SENSOR 2
BRAKE FLUID LEVEL SWITCH
BRAKE/
BRN WIRE
CLUTCH PEDAL STROKE SENSOR
COMPUTER DATA LINES SYSTEM
ELECTRIC VACUUM PUMP
ELECTRIC VACUUM PUMP CONTROL UNIT
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE CD
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOLD IND
HOLD SYSTEM IND
HOT W/ DC-DC
JUNCTION BOX D
LT BLU WIRE
LT GRN WIRE
M/T
PNK WIRE
RED WIRE
SYSTEM IND
VSA IND
VSA OFF IND
VSA OFF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> BRAKE BOOSTER PRESSURE SENSOR 1
