Acura Integra IV (2022-2024) auto/ int off low high mist Wiring diagram
This page shows the only wiring diagram for the component.auto/ int off low high mist, which is found in the car Acura Integra IV (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto/ int off low high mist (1 of 1)
AUTO/ INT LOW OFF
AUTO/ INT OFF LOW HIGH MIST
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH PEDAL POSITION SWITCH A
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
INTERMITTED DWELL TIME CONTROLLER
MIST HIGH
PCM
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RELAY CONTROL MODULE
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER MOTOR
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER CONTROL UNIT/MOTOR
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit (2 of 2) -> AUTO/ INT OFF LOW HIGH MIST
