Charging circuit, canada for Acura Integra III (1993-2001)
Charging circuit, canada
ALTERNATOR
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CHARGE IND
ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT SIDE KICK PANEL)
FUSE 15 ALTERNATOR (SP SENSOR)
FUSE 41 BATTERY
GAUGE AS- SEMBLY
HOT IN ON OR START
INTEGRATED CONTROL UNIT
LO OIL PSI IND. CKT.
POWER DISTRIBUTION SYSTEM
RED WIRE
STARTER SOLENOID
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
