Moonroof circuit for Acura Integra III (1993-2001)
Moonroof circuit
BLK WIRE
CLOSE
FUSE 24 P/W RLY SUN ROOF RLY
FUSE 49 DR LOCK, SUN ROOF
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HATCHBACK SEDAN
HOT AT ALL TIMES
HOT IN ON OR START
MOON ROOF MOTOR (SEDAN: CENTER FRONT OF ROOF, HATCHBACK: CENTER REAR OF ROOF)
MOON ROOF RELAY (ABOVE LEFT KICK PANEL)
MOON- ROOF SWITCH
OFF
RED WIRE
UNDER- DASH FUSE/ RELAY BOX
UNDER- HOOD FUSE/ RELAY BOX
UNDERDASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
