Power antenna circuit for Acura Integra III (1993-2001)
Power antenna circuit
ANTENNA
ANTENNA LEAD
BLK WIRE
DN UP
FUSE 28
FUSE 43
HOT AT ALL TIMES
HOT IN ACCY OR RUN
LIMIT SWITCHES
OFF ON
POWER ANTENNA MOTOR (IN LUGGAGE COMPARTMENT, BEHIND LEFT TRIM PANEL)
POWER ANTENNA RELAY
STEREO RADIO/ CASSETTE PLAYER
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT/RED WIRE
WHT/YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
