Car Wiring Diagrams for Instrument illumination circuit for Acura Integra III (1993-2001)

A/T GEAR POSITION CONSOLE LIGHT A/T GEAR POSITION SWITCH ALL MODELS EXCEPT RS ASH TRAY LIGHT BLK WIRE BRIGHT CIGARETTE LIGHTER CIGARETTE LIGHTER LIGHT CLOCK COMBINATION LIGHT SWITCH CRUISE CONTROL DIMMING CITRCUIT CRUISE CONTROL MAIN SWITCH DASH LIGHTS BRIGHTNESS CONTROLLER DIMMER CIRCUIT FUSE 30 INSTRUMENT LIGHTS FUSE 51 +B SMALL GAUGE ASSEMBLY GLOVE BOX LIGHT HAZARD WARNING SWITCH HEAD OFF HEADLIGHT SWITCH HEATER CONTROL PANEL HOT AT ALL TIMES ILLUMI- NATION (3 BULBS) INTEGRATED CONTROL UNIT LIGHT FLASHER RELAY (W/ SECURITY SYSTEM) OPTION CONNECTOR (DASH LIGHTS) PARK REAR WINDOW DEFOGGER SWITCH RED WIRE RED/GRN WIRE STEREO RADIO/ CASSETTE PLAYER UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT, NEAR BATTERY) WHT WIRE
