Car Wiring Diagrams for Courtesy lamps circuit for Acura Integra III (1993-2001)

1 3 (W/O MOONROOF) (W/MOONROOF) ALL MODELS EXCEPT USA RS ALL MODELS EXCEPT USA RS MODEL BLK WIRE BLU WIRE CARGO AREA LIGHT CEILING LIGHT DOOR OPEN INDICATOR LIGHT DRIVER'S DOOR SWITCH (CLOSED W/DOOR OPEN) FRONT PASSENGER'S DOOR SWITCH (CLOSED W/DOOR OPEN) FUSE 25 METER FUSE 43 INTERIOR LIGHT FUSE GAUGE ASSEMBLY GRN WIRE GRY WIRE HATCH LATCH LATCH SWITCH (CLOSED W/HATCH OPEN) HATCHBACK HATCHBACK SEDAN HOT AT ALL TIMES HOT IN ON OR START INTEGRATED CONTROL UNIT LT GRN WIRE LT GRN/RED WIRE LT LT ON OFF DOOR RED WIRE SECURITY SYSTEM CONNECTOR (OPTION) SECURITY SYSTEM CONNECTOR (OPTION) (BELOW LEFT SIDE OF DASH) SEDAN SEDAN ONLY SPOT- LIGHTS TRUNK LATCH SWITCH (CLOSED W/TRUNK OPEN) TRUNK LID/ HATCH OPEN INDICATOR LIGHT TRUNK LIGHT UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT NEAR BATTERY) USA RS MODEL W/O MOONROOF WHT WIRE WHT/RED WIRE YEL WIRE
