Headlamps & fog lamps circuit, without drl for Acura Integra III (1993-2001)
Headlamps & fog lamps circuit, without drl
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
FLASH- TO- PASS SWITCH OFF ON
FOGLIGHT IN-LINE FUSE (LOWER LEFT OF STEERING COLUMN)
FOGLIGHT RELAY
FOGLIGHT SWITCH
FUSE 21 R. HEADLIGHT LOW BEAM
FUSE 22 L. HEADLIGHT LOW BEAM
FUSE 4 R. HEADLIGHT HIGH BEAM
FUSE 48 HEADLIGHT
FUSE 5 L. HEADLIGHT HIGH BEAM
GAUGE ASSEMBLY HIGH BEAM INDICATOR
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
J/C
LEFT FOGLIGHT
LEFT HEADLIGHT (LOW)
NCA WIRE
OFF
OFF HEAD OFF DIMMER SWITCH LO PARK PARK
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOGLIGHT
RIGHT HEADLIGHT (HIGH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT, NEAR BATTERY)
WHT WIRE
