Back-up lamps circuit for Acura Integra III (1993-2001)
Back-up lamps circuit
A/T
A/T GEAR POSITION SWITCH (BELOW CENTER CONSOLE, AT BASE OF SHIFT LEVER)
BACK-UP LIGHT SWITCH (ON LOWER RIGHT SIDE OF TRANSAXLE)
BLK WIRE
BLK/ GRN WIRE
FUSE 19 BACK-UP LIGHT
GRN BLK/ WIRE
GRN WIRE
GRN/BLK WIRE
HATCHBACK
HOT IN ON OR START
LEFT BACK-UP LIGHT
M/T
RIGHT BACK-UP LIGHT
SEDAN
TRAILER CONNECTOR
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
YEL WIRE
