Acura Integra III (1993-2001) trunk light Wiring diagram
This page shows the only wiring diagram for the component.trunk light, which is found in the car Acura Integra III (1993-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk light (1 of 1)
1 3 (W/O MOONROOF) (W/MOONROOF)
ALL MODELS EXCEPT USA RS
ALL MODELS EXCEPT USA RS MODEL
BLK WIRE
BLU WIRE
CARGO AREA LIGHT
CEILING LIGHT
DOOR OPEN INDICATOR LIGHT
DRIVER'S DOOR SWITCH (CLOSED W/DOOR OPEN)
FRONT PASSENGER'S DOOR SWITCH (CLOSED W/DOOR OPEN)
FUSE 25 METER
FUSE 43 INTERIOR LIGHT FUSE
GAUGE ASSEMBLY
GRN WIRE
GRY WIRE
HATCH LATCH LATCH SWITCH (CLOSED W/HATCH OPEN)
HATCHBACK
HATCHBACK SEDAN
HOT AT ALL TIMES
HOT IN ON OR START
INTEGRATED CONTROL UNIT
LT GRN WIRE
LT GRN/RED WIRE
LT LT
ON OFF DOOR
RED WIRE
SECURITY SYSTEM CONNECTOR (OPTION)
SECURITY SYSTEM CONNECTOR (OPTION) (BELOW LEFT SIDE OF DASH)
SEDAN
SEDAN ONLY
SPOT- LIGHTS
TRUNK LATCH SWITCH (CLOSED W/TRUNK OPEN)
TRUNK LID/ HATCH OPEN INDICATOR LIGHT
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT NEAR BATTERY)
USA RS MODEL
W/O MOONROOF
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> TRUNK LIGHT
