Acura Integra III (1993-2001) shft lk circuit ctrl Wiring diagram
This page shows the only wiring diagram for the component.shft lk circuit ctrl, which is found in the car Acura Integra III (1993-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shft lk circuit ctrl (1 of 1)
1 2 (CRUISE) BRAKE SWITCH (ABOVE BRAKE PEDAL)
2 3 (CRUISE)
A/T GEAR POSITION SWITCH (BASE OF SHIFT LEVER)
BLK WIRE
BLU WIRE
BRAKE SWITCH INPUT
ENGINE CONTROLS SYSTEM
FUSE 25 METER
FUSE 52 HORN, STOP
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 33 INTERLOCK UNIT
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
INTERLOCK CONTROL UNIT
J/C 418 (LEFT KICK PANEL)
KEY INTERLOCK SOLENOID
KEY INTERLOCK SWITCH
PARKING PIN SWITCH (ON SHIFT LEVER)
RED/BLK WIRE
SENSOR OUTPUT
SHFT LK CIRCUIT CTRL
SHIFT LOCK SOLENOID (FRONT LEFT SIDE OF CENTER CONSOLE)
STEERING LOCK
THROTTLE POSITION SENSOR
TRANSMISSION CONTROL MODULE (BEHIND LEFT KICK PANEL)
UNDER- DASH FUSE/ RELAY BOX
UNDER- HOOD FUSE/ RELAY BOX
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Shift interlock circuit -> SHFT LK CIRCUIT CTRL
