Acura Integra III (1993-2001) rear window defogger element wiring diagram
This page shows the only wiring diagram for the component.rear window defogger element, which is found in the car Acura Integra III (1993-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear window defogger element wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/YEL WIRE
CONDENSER (BEHIND LEFT QUARTER PANEL TRIM)
FUSE 16
HATCHBACK
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY BOX FUSE 50
HOT IN ON
ILLUMI- NATION
INTEGRATED CONTROL UNIT
OFF 4 2
ON INDICATOR
REAR DEFOGGER TIMER CIRCUIT
REAR WINDOW DEFOGGER ELEMENT
REAR WINDOW DEFOGGER RELAY (ABOVE LEFT KICK PANEL)
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/BLK WIRE
SEDAN
UNDERDASH FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
Go to component -> Defoggers circuit -> REAR WINDOW DEFOGGER ELEMENT
