Acura Integra III (1993-2001) int/park ctrl Wiring diagram
This page shows the only wiring diagram for the component.int/park ctrl, which is found in the car Acura Integra III (1993-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int/park ctrl (1 of 1)
BATTERY
BLK WIRE
BLK/GRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BULB CK OUT
CEILING LT ON
DEFOGGER SYSTEM
DR DOOR SW
DRIVER'S DOOR SWITCH
ENGINE CONTROLS SYSTEM
FR WIPER FR WASH FUSE 26
GRN/BLU WIRE
GRN/RED WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
HOT IN ON OR
HOT WITH ENGINE CRANKING
HOT WITH LIGHTS ON
IGNITION
INST LIGHTS FUSE 30
INST. CLUSTER SYSTEM
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT CLUSTER SYSTEM (BRAKE SYS. IND. LIGHT)
INT WIPER ON
INT/PARK CTRL
INTEGRATED CONTROL UNIT
INTERIOR LIGHT FUSE 43
KEY SW IN
LIGHTS ON IN
LT BLU WIRE
LT GRN/RED WIRE
METER FUSE 25
OIL PRESS IN
OIL PRESS IND
PARK IN
POWER DIST SYSTEM
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
RR DEF TIMER
SEAT BELT IN
START SIG IN
STARTER SIGNAL FUSE 31
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM (ALTERNATOR)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
WARNING SYSTEM
WASH ON IN
WHT/BLU WIRE
WHT/RED WIRE
WIPER/WASH
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM (W/ COMBINED WIPER/WASHER OPERATION)
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
