Acura Integra III (1993-2001) abs indicator ckt Wiring diagram
This page shows the only wiring diagram for the component.abs indicator ckt, which is found in the car Acura Integra III (1993-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram abs indicator ckt (1 of 1)
1 INDICATOR
2 INDICATOR
A/T GEAR POSITION INDICATOR
ABS INDICATOR CKT
ABS INDICATOR LIGHT
ALTERNATOR
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (ON BOTTOM OF BRAKE FLUID RESERVOIR CAP)
BRAKE IND CTRL P.B. SW IN
CANADA
CHARGING SYSTEM INDICATOR LIGHT
CRUISE CONTROL INDICATOR LIGHT
CRUISE CTRL DIM- MING CKT
DIMMING CIRCUIT
DIMMING CKT.
DISTRIBUTOR ASSEMBLY
DOOR OPEN INDICATOR LIGHT
DRIVER'S SEAT BELT SWITCH
ENGINE COOLANT TEMPERATURE (ECT) GAUGE SENDING UNIT (ON REAR OF CYLINDER HEAD)
ENGINE OIL PRESSURE IND FLASHER CKT
ENGINE OIL PRESSURE SWITCH (LOWER LEFT SIDE OF ENGINE, LEFT OF OIL FILTER)
FROM FUEL GAUGE (DIAGRAM 1 OF 2)
FROM MAINTENANCE REMINDER LIGHT (DIAGRAM 1 OF 2)
FUEL GAUGE SEND- ING UNIT
FUEL TANK UNIT (IN FUEL TANK, UNDER ACCESS COVER IN TRUNK)
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
HIGH BEAM INDICATOR LIGHT
IGNITION CONTROL MODULE (ICM) ENGINE SPEED OUTPUT
ILLUM (3 BULBS)
INTE- GRATED CONTROL UNIT
INTE- GRATED CONTROL UNIT BRAKE BULB CHECK CKT
J/C
KEY-IN SEAT BELT REMINDER CKT
LEFT TURN SIGNAL INDICATOR LIGHT
N INDICATOR
P INDICATOR
PARK BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER)
PARKING BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER)
R INDICATOR
RED WIRE
RED/BLU WIRE
RIGHT TURN SIGNAL INDICATOR LIGHT
RPM INPUT RPM INPUT
SRS INDICATOR CKT
SRS INDICATOR LIGHT
TEST TACHOMETER CONNECTOR (LEFT REAR CORNER OF ENGINE COMPT)
THERM- ISTOR
TRUNK LID/HATCH OPEN INDICATOR LIGHT
UNDER- DASH FUSE/ RELAY BOX
USA
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> ABS INDICATOR CKT
