Acura ILX I facelift (2015-2018) washer main relay under-dash fuse holder c Wiring diagram
This page shows the only wiring diagram for the component.washer main relay under-dash fuse holder c, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer main relay under-dash fuse holder c (1 of 1)
A/C COMPRESSOR CLUTCH RELAY RELAY HOLDER B UNDER-HOOD FUSE/RELAY BOX
A/C CONDENSER FAN RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BOARD (DIAGRAM 3 OF 6)
D/L DOOR LOCK RELAY
D/L DOOR UNLOCK RELAY
D/L UNLOCK RELAY
ELD
EPS CONTROL UNIT
ETCS CONTROL RELAY
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FUSE 1 1
FUSE 1-3
FUSE 1-4
FUSE 1-5
FUSE 1-6
FUSE 16
FUSE 17
FUSE 2-1
FUSE 2-10
FUSE 2-11
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 2-8
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 25
FUSE 26
FUSE 27
FUSE 37
FUSE 38
FUSE 39
FUSE 41
FUSE 42
GRN WIRE
LEFT HEADLIGHT LOW BEAM RELAY
LT BLU WIRE
MICU
PGM-FI MAIN RELAY 1
PNK WIRE
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CIRCUIT BOARD
RELAY HOLDER A
RIGHT HEADLIGHT LOW BEAM RELAY
STARTER
STARTER CUT RELAY 1
STEREO AMPLIFIER
TO FUSE 17 (DIAGRAM 2 OF 6)
TO FUSE 2-7 (DIAGRAM 6 OF 6)
TO FUSE 29 (DIAGRAM 2 OF 6)
TO FUSE 44 (DIAGRAM 5 OF 6)
TO RELAY CIRCUIT
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
TRUNK LID RELEASE ACTUATOR RELAY
UNDER- DASH FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WASHER MAIN RELAY UNDER-DASH FUSE HOLDER C
WHT WIRE
WINDSHIELD WIPER MOTOR RELAY RELAY HOLDER B
YEL WIRE
Go to component -> Power distribution circuit (1 of 6) -> WASHER MAIN RELAY UNDER-DASH FUSE HOLDER C
