Acura ILX I facelift (2015-2018) trunk lid latch switch/trunk lid release actuator Wiring diagram
This page shows the only wiring diagram for the component.trunk lid latch switch/trunk lid release actuator, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid latch switch/trunk lid release actuator (1 of 1)
A/C CONDENSER FAN MOTOR
AUDIO DISPLAY UNIT
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BODY
BRN WIRE
CABLE REEL
CENTER DISPLAY UNIT
ELD
FAN CONTROL RELAY
GAUGE CONTROL MODULE
GRY WIRE
HIGH MOUNT BRAKE LIGHT
HVAC DISPLAY UNIT
INTERFACE DIAL
KEYLESS BUZZER
LEFT BACKUP LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT INNER BRAKE LIGHT/ INNER TAILLIGHT
LEFT LED CONTROL UNIT ASSEMBLY
LEFT LICENSE PLATE LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT/ BRAKE LIGHT
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
RELAY HOLDER A
RIGHT BACKUP LIGHT
RIGHT INNER BRAKE LIGHT/ INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT/ BRAKE LIGHT
STEERING ANGLE SENSOR
TRUNK LID LATCH SWITCH/TRUNK LID RELEASE ACTUATOR
TRUNK LID OUTER HANDLE SWITCH
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ COLOR MULTI-INFORMATION DISPLAY
W/ NAVIGATION
W/ TOUCH SCREEN
W/O COLOR MULTI-INFORMATION DISPLAY
W/O NAVIGATION
Go to component -> Ground distribution circuit (3 of 4) -> TRUNK LID LATCH SWITCH/TRUNK LID RELEASE ACTUATOR
