Acura ILX I facelift (2015-2018) left side first impact sensor Wiring diagram
This page shows the only wiring diagram for the component.left side first impact sensor, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side first impact sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT BELT OUTER LAP TENSIONER
DRIVER'S SEAT BELT TENSIONER
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SIDE AIR BAG INFLATOR
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
LEFT SIDE CURTAIN AIR BAG INFLATOR
LEFT SIDE FIRST IMPACT SENSOR
LEFT SIDE SECOND IMPACT SENSOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR
RIGHT SIDE FIRST IMPACT SENSOR
RIGHT SIDE SECOND IMPACT SENSOR
SRS UNIT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> LEFT SIDE FIRST IMPACT SENSOR
