Acura ILX I facelift (2015-2018) high indi- cator Wiring diagram
This page shows the only wiring diagram for the component.high indi- cator, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high indi- cator (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
DRIVER'S SEAT HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 14
FUSE 22
GRN WIRE
GRY WIRE
HIGH INDI- CATOR
HIGH INDICATOR
HOT AT ALL TIMES
HOT IN ON
LOW INDICATOR
LT GRN WIRE
ORG/ WIRE
RED WIRE
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Heated seats circuit -> HIGH INDI- CATOR
