Acura ILX I facelift (2015-2018) front hfl-anc/ active sound control microphone Wiring diagram
This page shows the only wiring diagram for the component.front hfl-anc/ active sound control microphone, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front hfl-anc/ active sound control microphone (1 of 1)
ANC/ ACTIVE SOUND CONTROL UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BRN WIRE
CONSOLE ACCESSORY POWER SOCKET
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SEAT RELAY HOLDER
FRONT HFL-ANC/ ACTIVE SOUND CONTROL MICROPHONE
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT RELAY HOLDER
FRONT PASSENGER'S WEIGHT SENSOR UNIT
FUEL TANK UNIT
GLOVE BOX LIGHT
GRY WIRE
HOMELINK UNIT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
MICU
MULTIPURPOSE CAMERA UNIT
PARK PIN SWITCH
POWER SEAT CONTROL UNIT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT SIDE BSI RADAR UNIT
ROOF CONSOLE MODULE
SHIFT POSITION INDICATOR
STEREO AMPLIFIER
SUNLIGHT SENSOR
TELEMATICS CONTROL UNIT
TRUNK LID OPENER MAIN SWITCH
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Ground distribution circuit (4 of 4) -> FRONT HFL-ANC/ ACTIVE SOUND CONTROL MICROPHONE
