Acura ILX I facelift (2015-2018) 32 bit microcomputer + eeprom 32 bit microcomputer + flash rom Wiring diagram
This page shows the only wiring diagram for the component.32 bit microcomputer + eeprom 32 bit microcomputer + flash rom, which is found in the car Acura ILX I facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 32 bit microcomputer + eeprom 32 bit microcomputer + flash rom (1 of 1)
32 BIT MICROCOMPUTER + EEPROM 32 BIT MICROCOMPUTER + FLASH ROM
AIR CONDITIONING SYSTEM
AUTO
B-CAN H B-CAN
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTOR
CRUISE LIGHTS DIMMING CIRCUIT
DIMMER/ FLASH-TO- PASS SWITCH
FOG LIGHT RELAY
FOG LIGHT SWITCH
FRONT FOG LIGHT IND
FUSE 12
FUSE 20
FUSE 23
FUSE 29
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT LOW BEAM RELAY
LEFT LED CONTROL UNIT ASSEMBLY
LIGHTS ON IND
LT BLU WIRE
LT GRN WIRE
MICU
OFF PARK
OPTIONAL
ORG/ WIRE
PASS
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
RIGHT FOG LIGHT
RIGHT HEADLIGHT LOW BEAM RELAY
RIGHT LED CONTROL UNIT ASSEMBLY
SUNLIGHT SENSOR
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ COLOR MULTI-INFORMATION DISPLAY W/O COLOR MULTI-INFORMATION DISPLAY
WARNING DRIVE CIRCUIT
WHT WIRE
Go to component -> Headlights circuit -> 32 BIT MICROCOMPUTER + EEPROM 32 BIT MICROCOMPUTER + FLASH ROM
