Tire pressure monitoring circuit for Acura ILX I (2012-2015)

Tire pressure monitoring circuit

Get access

+B TPMS BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT ENGINE COMPT) F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 29 FUSE 40 FUSE 5 GAUGE CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START INDICATOR K LINE LOW TIRE PRESSURE INDICATOR LT BLU WIRE MAIN CIRCUIT MULTI-INFORMATION DISPLAY RED WIRE TPMS CONTROL UNIT (LEFT END OF DASH) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (HYBRID: LEFT REAR OF WHT WIRE
