Power door locks circuit for Acura ILX I (2012-2015)

Power door locks circuit (1 of 7)

ILX Acura I (2012-2015): Power door locks circuit (1 of 7)

Get access

ANSWER BACK BUZZER (HYBRID: BEHIND LEFT SIDE OF REAR BUMPER) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM D/L DOOR UNLOCK RELAY D/L LOCK RELAY D/L UNLOCK RELAY DOOR LOCK KNOB FUSE 15 FUSE 33 FUSE 8 FUSE 41 FUSE 30 FUSE 32 FUSE 44 FUSE 42 FUSE 9 GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HORNS SYSTEM HYBRID EXCEPT HYBRID LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH LOCK LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE PNK WIRE RED WIRE RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH UNLOCK WHT WIRE YEL WIRE

Power door locks circuit (2 of 7)

ILX Acura I (2012-2015): Power door locks circuit (2 of 7)

Get access

6 7 PNK WIRE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) DOOR LOCK KNOB KEY DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH EXCEPT HYBRID FUSE FUSE FUSE 2-3 2-1 GRN WIRE GRY WIRE HYBRID EXCEPT HYBRID LOCK LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE POWER WINDOW MASTER SWITCH TRUNK LID OPENER MAIN SWITCH UNLOCK WHT WIRE YEL WIRE

Power door locks circuit (3 of 7)

ILX Acura I (2012-2015): Power door locks circuit (3 of 7)

Get access

1 2 3 4 5 6 PPL 6 7 PNK WIRE BLK (OR BRN) WIRE BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM CONTROL UNIT) DOOR LOCK KNOB EXCEPT HYBRID A/T EXCEPT HYBRID M/T FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE GRN WIRE HOT W/ ACCESSORY RELAY ENERGIZED HYBRID EXCEPT HYBRID LOCK LT BLU WIRE LT GRN WIRE OPTIONAL CONNECTOR ORG/ WIRE PASSENGER DOOR LOCK SWITCH PCM (LEFT SIDE OF ENGINE COMPT) PNK WIRE PPL RED WIRE TRANSMISSION RANGE SWITCH (A/T) TRANSMISSION RANGE SWITCH (A/T) (ON TRANSMISSION HOUSING) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNLOCK WHT WIRE YEL WIRE

Power door locks circuit (4 of 7)

ILX Acura I (2012-2015): Power door locks circuit (4 of 7)

Get access

1 2 3 4 5 6 PPL BACKUP CONTROL UNIT (LEFT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 2 GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK 1 2 3 4 5 6 7 8 9 WIRE PNK PPL WIRE PNK WIRE PPL PPL 31 32 33 34 35 36 37 RED WIRE WHT WIRE YEL WIRE

Power door locks circuit (5 of 7)

ILX Acura I (2012-2015): Power door locks circuit (5 of 7)

Get access

BLK WIRE BLU WIRE BRN WIRE CONTROL CIRCUIT DATA LINK CONNECTOR DRIVER'S JUNCTION BOX 1 ENGINE START/STOP SWITCH GRN WIRE GRY WIRE IMMO- BILIZER I/F LF ANTENNA LT GRN WIRE ORG/ WIRE PNK 1 2 3 4 5 6 7 8 9 WIRE PNK PPL WIRE PNK WIRE PPL PPL 31 32 33 34 35 36 37 RED WIRE WHT WIRE YEL WIRE

Power door locks circuit (6 of 7)

ILX Acura I (2012-2015): Power door locks circuit (6 of 7)

Get access

B-CAN B-CAN B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRAKE IND BRN WIRE COMPUTER DATA LINES SYSTEM DOOR IND DOOR LF ANTENNA DRIVER'S DOOR OUTER HANDLE EXCEPT HYBRID FRONT PASSENGER'S DOOR OUTER HANDLE GAUGE CONTROL MODULE GRN WIRE GRY WIRE HYBRID EXCEPT HYBRID IMMOBILIZER IND INDICATOR DRIVE CIRCUIT KEYLESS ACCESS SYSTEM IND LOCK SWITCH LOCK SWITCH TOUCH SENSOR LT BLU WIRE LT GRN WIRE MAIN CIRCUIT ORG/ WIRE PNK WIRE PPL RED WIRE REMOTE + RF UNIT 1 SECURITY IND TOUCH SENSOR DOOR LF ANTENNA TRUNK LID OUTER HANDLE SWITCH WHT WIRE YEL WIRE

Power door locks circuit (7 of 7)

ILX Acura I (2012-2015): Power door locks circuit (7 of 7)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HYBRID EXCEPT HYBRID KEYLESS ACCESS CONTROL UNIT (CENTER OF DASH) LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE REMOTE + RF UNIT 2 WHT WIRE YEL WIRE
