Acura ILX I (2012-2015) windshield brake wiper fluid motor level relay switch Wiring diagram
This page shows the only wiring diagram for the component.windshield brake wiper fluid motor level relay switch, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield brake wiper fluid motor level relay switch (1 of 1)
ACCESSORY RELAY
BATTERY SENSOR
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
CONSOLE ACCESSORY WINDSHIELD POWER WASHER SOCKET MOTOR RELAY RELAY
D/L DR UNLOCK RELAY
D/L LOCK RELAY
D/L UNLOCK RELAY
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S LEFT POWER POWER WINDOW MIRROR MOTOR
ENGINE TRANSMISSION HOUSING
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
GAUGE CONTROL MODULE
MICU
MOONROOF CONTROL UNIT/ MOTOR
POWER CONTROL UNIT
POWER MIRROR SWITCH
POWER TRANSISTOR
POWER WINDOW MASTER SWITCH
REAR EPS WINDOW CONTROL DEFOGGER UNIT
RELAY CIRCUIT BOARD
SECURITY HOOD SWITCH
TPMS CONTROL UNIT
TRUNK LID RELEASE ACTUATOR RELAY
VSA OFF SWITCH
W/ NAVIGATION
W/O NAVIGATION
WASHER MAIN RELAY
WINDSHIELD BRAKE WIPER FLUID MOTOR LEVEL RELAY SWITCH
WINDSHIELD WIPER INTERMITTENT RELAY
Go to component -> Ground distribution circuit, except hybrid (1 of 4) -> WINDSHIELD BRAKE WIPER FLUID MOTOR LEVEL RELAY SWITCH
