Acura ILX I (2012-2015) ppl transmissions system Wiring diagram
This page shows the only wiring diagram for the component.ppl transmissions system, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl transmissions system (1 of 1)
1 2 PPL
8 6 5 11 10 9 12 7 PPL PPL PPL
AIR CONDITIONING SYSTEM
APP SENSOR (BIND CENTER OF DASH)
APP SENSOR A
APP SENSOR B
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPULSORY TURNING- OFF CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
EPS CONTROL UNIT (BEHIND RIGHT KICK PANEL)
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FTP SENSOR (TOP OF FUEL TANK)
FUSE 15
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
MALFUCTION INDICATOR
NEP
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PGM-FI SUB- RELAY
PNK STARTING/ CHARGING SYSTEM WIRE
PNK WIRE
PPL
PPL PPL
PPL TRANSMISSIONS SYSTEM
RED WIRE
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l hybrid, engine controls circuit (1 of 6) -> PPL TRANSMISSIONS SYSTEM
