Acura ILX I (2012-2015) power sunlight control sensor unit Wiring diagram
This page shows the only wiring diagram for the component.power sunlight control sensor unit, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power sunlight control sensor unit (1 of 1)
A/T GEAR POSITION INDICATOR
ACURALINK CONTROL UNIT (XM RECEIVER)
ANC/ACTIVE SOUND CONTROL UNIT
AUTOMATIC PASSENGER'S DIMMING VANITY INSIDE MIRROR MIRROR LAMP
BLK WIRE
CONSOLE ACCESSORY POWER SOCKET
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT POSITION SENSOR
DRIVER'S VANITY MIRROR LAMP
ENGINE START/STOP SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S FUEL SEAT HEATER TANK RELAY (HIGH) UNIT
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
GLOVE BOX LAMP)
HOMELINK UNIT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
MICU
ODS UNIT
POWER SUNLIGHT CONTROL SENSOR UNIT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
STEREO AMPLIFIER
TRUNK LID OPENER MAIN SWITCH
W/ NAVIGATION
YEL WIRE
Go to component -> Ground distribution circuit, except hybrid (4 of 4) -> POWER SUNLIGHT CONTROL SENSOR UNIT
