Acura ILX I (2012-2015) left right fog fog lamp lamp Wiring diagram
This page shows the only wiring diagram for the component.left right fog fog lamp lamp, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right fog fog lamp lamp (1 of 1)
BACKUP CONTROL UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTUIN BOX
CKP SENSOR
CMP SENSOR
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DRIVER JUNCTUIN BOX 1
EGR VALVE/ EGR VALVE POSITION SENSOR
EXHAUST EXHAUST SIDE SIDE IGNITION IGNITION COIL 3 COIL 4
EXHAUST SIDE IGNITION COIL 1
EXHAUST SIDE IGNITION COIL 2
GRN WIRE
INTAKE INTAKE SIDE SIDE IGNITION IGNITION COIL 3 COIL 4
INTAKE SIDE IGNITION COIL 1
INTAKE SIDE IGNITION COIL 2
J/C
KEYLESS ACCESS CONTROL UNIT
LEFT RIGHT FOG FOG LAMP LAMP
PCM
PCM SHIELD
POWER UNIT
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP (HIGH)
RIGHT HEADLAMP LOW
ROCKER ARM OIL CONTROL SOLENOID A
ROCKER ARM OIL CONTROL SOLENOID B
SECONDARY
SENSOR 2
SERVO UNIT
TRANSMISSION RANGE SWITCH
VSA MODULATOR CONTROL UNIT
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit, hybrid (2 of 4) -> LEFT RIGHT FOG FOG LAMP LAMP
