Acura ILX I (2012-2015) front passenger's door speaker Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door speaker, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door speaker (1 of 1)
2 3 4 5 PPL PNK WIRE
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR SPEAKER
END OF DASH)
FRONT PASSENGER'S DOOR SPEAKER
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (UNDER LEFT FUSE 37
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
STEREO AMPLIFIER (LOWER LEFT CENTER OF DASH)
SUBWOOFER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation (4 of 4) -> FRONT PASSENGER'S DOOR SPEAKER
