Acura ILX I (2012-2015) d/l lock trunk lid relay release actuator relay Wiring diagrams
This page contains all the electrical diagrams for the component. d/l lock trunk lid relay release actuator relay, in which he is found in the car Acura ILX I (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram d/l lock trunk lid relay release actuator relay (1 of 2)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
D/L LOCK TRUNK LID RELAY RELEASE ACTUATOR RELAY
D/L UNLOCK D/L DR RELAY UNLOCK RELAY
ELD
EPS CONTROL UNIT
ETCS CONTROL RELAY
FUSE
FUSE 1 1
FUSE 1-5
FUSE 1-6
FUSE 2-1
FUSE 2-10
FUSE 2-11
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 2-8
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 25
FUSE 27
FUSE 41
FUSE FUSE
FUSE FUSE 1-3 1-4
GRN WIRE
LEFT HEADLIGHT LOW BEAM RELAY
LT BLU WIRE
MAGNETIC SWITCH
MICU
PGM-FI MAIN RELAY 1
POWER WINDOW RELAY
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CIRCUIT BOARD (IN UNDER-HOOD FUSE/RELAY BOX)
RIGHT HEADLIGHT LOW BEAM RELAY
STARTER
STARTER CUT RELAY 1
STEREO POWER WINDOW AMPLIFIER MASTER SWITCH
TAIL LIGHT RELAY
TO ACCESSORY RELAY (DIAGRAM 5 OF 6)
TO FUSE 17 (DIAGRAM 2 OF 6)
TO FUSE 29 (DIAGRAM 2 OF 6)
TO FUSE 44 (DIAGRAM 5 OF 6)
TO POWER CONTROL UNIT (DIAGRAM 6 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
TPMS CONTROL UNIT
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WASHER MAIN RELAY
WHT WIRE
WINDSHIELD WIPER MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 6) -> D/L LOCK TRUNK LID RELAY RELEASE ACTUATOR RELAY
Wiring diagram d/l lock trunk lid relay release actuator relay (2 of 2)
A/C COMPRESSOR CLUTCH RELAY
A/C STARTER CONDENSER CUT FAN RELAY RELAY 1
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
D/L LOCK TRUNK LID RELAY RELEASE ACTUATOR RELAY
D/L UNLOCK D/L DR RELAY UNLOCK RELAY
ELD
ETCS CONTROL RELAY
FUSE
FUSE 1-5
FUSE 1-6
FUSE 2-1
FUSE 2-10
FUSE 2-2
FUSE 2-3
FUSE 2-6
FUSE 2-8
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 25
FUSE 27
FUSE 41
FUSE FUSE
FUSE FUSE 1-1 1-2
FUSE FUSE 1-3 1-4
FUSE FUSE 2-11 2-4
FUSE FUSE 2-5
GRN WIRE
LEFT HEADLIGHT LOW BEAM RELAY
LT BLU WIRE
MAGNETIC SWITCH
MICU
PGM-FI MAIN RELAY 1
POWER WINDOW RELAY
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CIRCUIT BOARD (IN UNDER-HOOD FUSE/RELAY BOX)
RIGHT HEADLIGHT LOW BEAM RELAY
SERVO EPS UNIT CONTROL UNIT
SERVO UNIT
STARTER
STEREO POWER WINDOW AMPLIFIER MASTER SWITCH
TAIL LIGHT RELAY
TO ACCESSORY RELAY (DIAGRAM 5 OF 6)
TO DC-DC CONVERTER (DIAGRAM 3 OF 6) WINDSHIELD WIPER MOTOR RELAY
TO FUSE 19 (DIAGRAM 2 OF 6)
TO FUSE 28 (DIAGRAM 2 OF 6)
TO FUSE 44 (DIAGRAM 5 OF 6)
TO POWER CONTROL UNIT (DIAGRAM 6 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
TPMS CONTROL UNIT
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH)
VSA MODULATOR CONTROL UNIT
WASHER MAIN RELAY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 6) -> D/L LOCK TRUNK LID RELAY RELEASE ACTUATOR RELAY
