Acura ILX I (2012-2015) automatic passenger's dimming vanity homelink inside mirror unit mirror lamp Wiring diagram
This page shows the only wiring diagram for the component.automatic passenger's dimming vanity homelink inside mirror unit mirror lamp, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic passenger's dimming vanity homelink inside mirror unit mirror lamp (1 of 1)
A/T GEAR POSITION INDICATOR
ACURALINK CONTROL UNIT (XM RECEIVER)
AUDIO NAVIGATION STEREO UNIT AMPLIFIER
AUTOMATIC PASSENGER'S DIMMING VANITY HOMELINK INSIDE MIRROR UNIT MIRROR LAMP
BLK WIRE
BRN WIRE
CONSOLE ACCESSORY POWER SOCKET
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT POSITION SENSOR
DRIVER'S VANITY MIRROR LAMP
ENGINE START/STOP SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S FUEL SEAT HEATER TANK RELAY (HIGH) UNIT
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
HFL- NAVIGATION ANC/ACTIVE SOUND CONTROL MICROPHONE
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
MCM
MICU
MPI MODULE
ODS UNIT
PARK PIN SWITCH
POWER CONTROL UNIT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
ROOF CONSOLE MODULE
SUNLIGHT GLOVE SENSOR BOX LAMP
TRUNK LID OPENER MAIN SWITCH
YEL WIRE
Go to component -> Ground distribution circuit, hybrid (4 of 4) -> AUTOMATIC PASSENGER'S DIMMING VANITY HOMELINK INSIDE MIRROR UNIT MIRROR LAMP
