Acura ILX I (2012-2015) auto gauge navigation interface control switch panel dial module Wiring diagram
This page shows the only wiring diagram for the component.auto gauge navigation interface control switch panel dial module, which is found in the car Acura ILX I (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto gauge navigation interface control switch panel dial module (1 of 1)
A/C COMPRESSOR DRIVER
A/C CONDENSER FAN MOTOR
ANSWER BACK BUZZER
AUTO GAUGE NAVIGATION INTERFACE CONTROL SWITCH PANEL DIAL MODULE
AUXILIARY ELECTRIC WATER PUMP
BATTERY MODULE
BLK WIRE
BLU WIRE
CABLE REEL
CRUISE CONTROL COMBINATION SWITCH STEERING ANGLE SENSOR
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
ELD
ELECTRIC STEERING LOCK
FAN CONTROL RELAY
GRY WIRE
HIGH MOUNT BRAKE LAMP
J/C
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP (HIGH)
LEFT HEADLAMP (LOW)
LEFT LICENSE PLATE LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT TAILLIGHT, BRAKE LAMP
MCM SHIELD IPU FAN MODULE
MOTOR ROTOR
NAVIGATION DISPLAY UNIT
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
POSITION SENSOR SHIELD
RIGHT LEFT BACKUP BACKUP LAMP LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAILLIGHT, BRAKE LAMP
SENSOR 2 SENSOR 1
SENSOR 3
SENSOR 4
SRS UNIT
STEERING GEAR BOX
TRUNK LID OUTER HANDLE SWITCH
TRUNK LID RIGHT LATCH LICENSE SWITCH/TRUNK PLATE LID RELEASE LAMP ACTUATOR
YEL WIRE
Go to component -> Ground distribution circuit, hybrid (3 of 4) -> AUTO GAUGE NAVIGATION INTERFACE CONTROL SWITCH PANEL DIAL MODULE
